Clean Energy Biogas Combined Heat Power 200KVA 160KW Three Phase Low Noise

Brand Name : SevenPower

Model Number : SP160B

Certification : CE

Place of Origin : Chengdu,China

MOQ : 1 Set

Delivery Time : 25days

Price : Negotiable

Payment Terms : L/C, T/T

Fuel : Biogas

CH4 : >=55%

Frequency : 50Hz,60Hz is available on request

RPM : 1500

Start : Electrical Auto start

Engine Type : Water-cooled

Overhauling Time : 25000hours

Altitude : <1000meters

Contact Now

Clean Energy China Biogas CHP 200KVA 160KW 3 Phase CE Verified

Biogas is well known as clean energy, biogas CHP solved the problem of livestock waste, reduce greenhouse gas emissions, generate both electricity and heat, with high overall efficiency to achieve maximum utilization of resources.
CHP Main Specifications


  Model SP160B
fuel Biogas
marks Synchro CHP
electrical output(KWe) kVA/kWe Continuous Power
200/160
thermal output(KWe) kWt 236
electrical efficiency % 33.6%
thermal efficiency % 49.6%
overall efficiency % 83.2%
frequency Hz 50
voltage V 400/230
gas inlet pressure kPa 3-5
dimension (soundproof type) mm*mm*mm 2900*1600*1800
net weight kg 3500
Biogas consumption m3/kW.h 0.42
Biogas consumption for one hours m3/h 67.2
db(A)@7m 59
Certificate CE
water-water heat exchanger SWEP
water-exhaust heat exchanger made of stainless steel
ignition system Impco
speed governor Woodward
gas filter Madas
zero regulator Kromschroeder
MCB ABB
GCB ABB
Controller   ComAp
Engine model STYER T12
Engine type 6 cylinders,4stroke,water-coolled
RPM 1500
Compression Ratio 11.0
Displacement 11.6L
Oil capacity 36L
Charging voltage 24V(DC)
Charging current 5A(DC)
Starting system Electic-start
model Meccalte
phase 3 phase 4 wires
insulation system class H
protection IP23
Cooling Type air cooled


Characters

Environmentally friendly design.
Long time R&D and testing ensure high reliability.
Comprehensive heat insulation to minimize heat loss.
CHP inner pipelines are made of full stainless steel material.
Maximum lower the noise level.
Maintenance friendly thanks to easy access.

Biogas Requirements

Composition Content
CH4 ≥55%
fluctuations value of biogas in pipeline <0.2Kpa
hydrogen <10%
sulfide, including hydrogen sulphide <200mg/m3
chlorine fluorine compounds,mainly chlorofluoromethane <15mg/m3
silicium <0.7mg/m3
ammonia <15mg/m3
liquid oil and hydrocarbons <50mg/m3
particles <5μm Impurity content<30mg/m3


Clean Energy Biogas Combined Heat Power 200KVA 160KW Three Phase Low Noise

For more information about each CHP, please consult with your sales representative.Thanks.

Biogas CHP On-site Picture(Installed In Year 2013)
Clean Energy Biogas Combined Heat Power 200KVA 160KW Three Phase Low Noise



More Information About Our Factory

Our Packing

Clean Energy Biogas Combined Heat Power 200KVA 160KW Three Phase Low Noise

Our Hannover Exhibition

Clean Energy Biogas Combined Heat Power 200KVA 160KW Three Phase Low Noise

Our Showroom In Germany

Clean Energy Biogas Combined Heat Power 200KVA 160KW Three Phase Low Noise



Our Customers' Visiting

Clean Energy Biogas Combined Heat Power 200KVA 160KW Three Phase Low Noise
